Automatic Rolling Shutter

Automatic Rolling Shutter
Product name:Automatic Rolling Shutter
Item:Rolling Door Operator
Details:

Advanced Features

  • Overheat protection
  • Electric and manual operation
  • Release chain in case of power failure
  • Limit switch unit enables precise adjustment of door in up and down positions
  • Safety device for preventing the vehicle or people from damage in case of roller chain is break off
  • Easy installation, legerity design, low noise, small power consumption
Technical data

Model

Input power

(V)

Output torque

(N.m)

Max. lift

kg

Rotate speed

r/min

Max. operating range

high :m

Rollinch

Chain

(ANSI standard)

KJ300

220

160

300

6.5

6

4”

41

KJ600

220

410

600

6.5

6

5”

50

KJ800

220

640

800

5

9

6”

50

KJ1000

220

710

1000

5.5

9

6”

60

KJ800S

380

850

800

5

9

6”

50

KJ1000S

380

870

1000

5.5

9

6”

60

KJ1300S

380

1400

1300

6.4

9

8”

60

KJ1500S

380

1600

1500

4.9

9

8”

80

KJ300DC

220

160

300

6.5

5

4”

41

KJ500DC

220

340

500

6.5

6

5”

50

*KJ500U 110V Max. lift 500 kg
Installation
